GM13 Standard 1.5mm HDPE Geomembrane Pond Linr Material

The GM13 Standard 1.5mm HDPE Geomembrane is a high-density polyethylene (HDPE) material manufactured by GEOSINCERE, specifically designed for waterproofing and protecting water bodies. Renowned for its excellent chemical resistance, UV stability, and aging characteristics, this geomembrane is widely used in various applications, including ponds, aquaculture, and wastewater treatment facilities. With a thickness of 1.5mm, it ensures strength and durability under diverse environmental conditions, effectively preventing water leakage and safeguarding soil and groundwater resources. GEOSINCERE’s geomembrane not only offers superior physical properties but also complies with environmental standards, providing a reliable long-term solution for waterproofing needs.

GEOSINCERE HDPE geomembranes are often chosen for pond lining due to their excellent chemical resistance, UV resistance, and high tensile strength.
  • GM13 Standard 1.5mm HDPE Geomembrane Pond Linr Material
  • GM13 Standard 1.5mm HDPE Geomembrane Pond Linr Material
  • GM13 Standard 1.5mm HDPE Geomembrane Pond Linr Material
  • GM13 Standard 1.5mm HDPE Geomembrane Pond Linr Material
  • GM13 Standard 1.5mm HDPE Geomembrane Pond Linr Material

Description

GM13 Standard 1.5mm HDPE Geomembrane Pond Linr Material丨GEOSINCERE

The GM13 Standard 1.5mm HDPE Geomembrane by GEOSINCERE offers numerous advantages that make it an ideal choice for water containment and environmental protection.

Durability and Longevity

This geomembrane is engineered to withstand extreme weather conditions, UV exposure, and chemical interactions, ensuring a long lifespan. Its robust construction minimizes risks of wear and tear, providing reliable performance over time.

Excellent Waterproofing

With a thickness of 1.5mm, the GM13 geomembrane effectively prevents water leakage, making it perfect for ponds and aquaculture applications. Its impermeable nature protects soil and groundwater from contamination, promoting sustainable practices.

Easy Installation

The lightweight design of the HDPE geomembrane allows for straightforward handling and installation. This ease of use can significantly reduce labor costs and project timelines, making it a cost-effective solution for various applications.

Eco-friendly Compliance

The GM13 geomembrane meets environmental standards, ensuring it is safe for use in sensitive ecological areas. By preventing water loss and protecting natural resources, it contributes to sustainable water management practices.

Product Description:

The GM13 Standard 1.5mm HDPE Geomembrane pond liner is indeed a high-quality pond lining material specifically designed for containment applications. It is manufactured using high-density polyethylene (HDPE), which is a robust and flexible plastic material. HDPE is chosen for pond lining due to its exceptional chemical resistance, ensuring that it can withstand exposure to various substances commonly found in ponds. Additionally, HDPE is known for its strength, providing reliable containment and preventing leakage or seepage from the pond. The combination of durability and flexibility makes the GM13 Standard 1.5mm HDPE Geomembrane pond liner an excellent choice for pond lining projects.



Product Parameter

Test Properties

Unit

Standard

Test frequency

GSO

10

GSO

15

GSO

20

GSO

25

Thickness

mm

D5994

per roll

1.00

1.50

2.00

2.50

Asperity Height

mm

D7446

Every 2nd roll (2)

0.25

Density

g/cc

D1505/0792

90.000kg

0.94

Tensile Properties

Yield Strength

Kn/m

D6693

Type Iv

9.000 kg

15

22

29

37

Break Strength

Kn/m

10

16

21

26

Yield Elongation

%

12

12

12

12

Break Elongation

%

100

100

100

100

Tear Resistance

N

D1004

20.000kg

125

187

249

311

Puncture Resistance

N

D4883

20,000kg

267

400

534

667

Stress Crack Resistance

hr

D5397(App)

per GRlGM-10

300 hr

Carbon black content

%

D4218

9.000kg

2.0-3.0%

Carbon black dispersion



D5596

20.000kg

For 10 different views: 9 in Categories 1 or 2 and 1 in Category 3

0xidative Induction Time

Standard OlT

min

D3895

90.000kg

100 min

High pressure OlT

D5885

90.000kg

400 min

Oven Aging at 85°C retained after 90 days

%

D5721

per each formulation

55%

Standard 0lT

D3895

80%

High pressure OlT

D5885

80%

UV Resistance

High Pressure OlT -% retained after 1600 hrs

%

D5885

per each formulation

50%

Roll Width

m





7

7

7

7

Roll Length

m





210

140

105

70

Size stability

%





2%



GM13 Standard 1.5mm HDPE Geomembrane Pond Liner Material Features



  1. Excellent Chemical Resistance: The HDPE material used in this geomembrane provides superior resistance to a wide range of chemicals, making it suitable for various industrial and agricultural applications.
  2. Flexible and Durable: The 1.5mm thickness offers a good balance of flexibility and durability, ensuring the geomembrane can conform to the shape of the pond while providing reliable containment.
  3. UV Resistance: The geomembrane is designed to withstand prolonged exposure to ultraviolet (UV) radiation from the sun, ensuring long-term performance and stability.
  4. High Tensile Strength: The GM13 Standard 1.5mm HDPE Geomembrane has a high tensile strength, which helps it withstand stress and pressure exerted by the contained liquids or materials.
  5. Seaming Capability: The geomembrane can be easily seamed or welded together to create larger lining systems, ensuring seamless and watertight installations.



Applications of GM13 Standard 1.5mm HDPE Geomembrane Pond Liner Material




- Pond lining for agricultural, decorative, or industrial ponds

- Reservoirs and water storage facilities

- Landfills and waste containment areas

- Mining and mineral processing operations

- Wastewater treatment ponds

- Aquaculture and fish farming



Product Packing

Selling Packing:Customer's company Logo mark can be designed and added.

Outer Packing:Packed in Double-layer woven bags to ensure smooth arrival and avoid rough handling.

Transport Packing: Put in the container.







Company Profile



Shandong GEOSINO New Material Co.,Ltd (Brand:Geosincere) is the professional geomembrane manufacturer and wholesaler located in Taian City, Shandong Province, PRChina. We are not a local overseas distributer, we are an professional manufacturer, exporter and wholesaler for geomembrane. GEOSINCERE is always committed to geomembrane research and development, manufacturing and installation services. We can provide our customers with most extensive lines of geomembranes for civil, mining, environmental and aquaculture engineering applications.




GEOSINCERE has been keeping on investing in technological innovation, manufacturing facilities improvement and turnkey engineering abilities. We have invested 10 million dollars into our manufacturing factory which is equipped with state-of-the-art automatic production lines to manufacture high quality geomembranes with optimized processes. Our extensive lines of geosynthetics products are well known for their ensured quality, high performance, excellent durability and best cost effectiveness. GEOSINCERE brand geomembranes products and solutions can meet your requirements by our solid technologies, innovative engineering solutions and excellent customer services. GEOSINCERE always tries our best to solve the most complex civil, mining and environmental challenges with our innovative and high performance geosynthetic products. Quality assurance, factory price and fast delivery time are our competitive advantages.




We have been exporting geomembranes to over 60 countries such as Australia, France, Sweden, UK, Hong Kong, Hungary, New Zealand, Poland, Mexico, Ecuador, Brazil, Pakistan, Bangladesh, Thailand, Vietnam, Malaysia, Indonesia, Singapore, Philippines, Sri Lanka, India, UAE, Saudi Arabia, Qatar, Kenya, Ghana, Ethiopia, Somalia, Nigeria, South Africa, Switzerland, Mongolia, etc.




Hope to be your partner!
